** Please wait for ALL photos to load **
Gil Schlehman searched the patent office for telegraph-related patents and
compiled the following list. It specifies the patent number, the person to
whom the patent is assigned, the location, the date, and any useful
information about the patented item.
The first three pages show a listing of all of the telegraph-related patent
numbers. These patent numbers were extracted by searching all of the patents
using a set of guidelines. The specific guidelines that were used for the
search are shown below the three pages of listings. These three pages and
the last page may be searched by using the Edit/Find(on this page)
feature of your browser.
The fourth page is a copy of the guidelines for locating the appropriate
indexing codes used to identify specific telegraph related instruments. This listing was
used to locate the telegraph items listed in the three preceding pages.
Clicking on this picture will either enlarge it for easier reading or bring up
an 'enlarge' button depending on how your computer is set up.
The fifth page shows the actual telegraph patent numbers that were extracted
by the preceding guidelines. This page may also be enlarged by clicking on
it.
The sixth page is a simple but VERY useful list of patent numbers and
their associated patent dates. This list should be helpful in dating
antiques for which the patent number is known.
Telegraph Patents (Searchable): Gil Schlehman - K9WDY Page 1 Patent #: Name Location Date #1 Notes: 13130 143341X Merritt Gally. Rochester,N.Y. 9-11-73 660469U (M) 812183 Vibroplex 842154 Vibroplex 855085 Benjamin Bellows Jul.9,1906 Mecograph 863810 Henry Smith Raliegh,N.C. Jul.17,1906 Vertical 864960 Josiah A. Carter Jr. Atlanta,Ga. Mar.4,1907 876391 Roy K. Patterson Chicago,Ill. Dec.29,1906 877915 Delaney strain relief attachment 883062 Wm.H.Teachworth (like a Vailograph) Jun.1,1906 attachment 884381 Mark S.Halig Weaver,Minn. May 22,1906 886755 Belows & Ambrose Behner Sep.27,1904 Combo (7-14-08) 893115 ,Minn. Apr.29,1907 Vailograph 912029 Harlie O.Putt Millbury,Ohio Feb.17,1908 Like Vailograph 913183 John C.Alderson El Casco,Calif. Sep.4,1906 180degree Bug 916538 Floyd W.DeTray Aurora,Ill. Aug.15,1907 920034 Paul Dinger & Louis Rose Jul.25,1907 923033 Dunn Jersey City,N.J. Dec.31,1908 926162 Wm.C.Achgill Oklahoma City,Ok. NOv.30,1908 90deg flip top 933726X Smith&Conkling New York N.Y. Jun.6.1908 935l64 George S.Perry Branford,Fla. Jan.28,1909 939383 Bellows-Dinger Jul.29,1907 939507 Hulit Sep.3,1908 947224 Delaney S.Orange,N.J. Mar.23,1907 45deg magnets 954298 Wm. M. Jackson Gastonia,N.C. May.27,1909 Vertical like Pendograph but sideways 977452 Jos. Russel Jones Port Arthur,Ontario Feb.9,1910 981845X Delaney Mar.23,1907 982638 Harry H.Smith Brooklyn, NY Jun.22,1910 Vert Vib Vail
Telegraph Patents (Searchable): Gil Schlehman - K9WDY Page 2 Patent #: Name Location Date #2 Notes: 1012906 Geo.Stamper Perry Dupont,Ga. Jan.26,1911 Jeremiah H.Kidwell 1019883 John A. Cox Parkersburg,W.Va. Sep.27,1910 Straight 1025471 Joseph R.Jones Detroit,Mich. May 29,1911 Straight 1031752 Russell S.Welty Sudbrook, Park,Md. Jul.19,1911 Release type 1036443 George V.Buquoi St.James, LA. Oct 30,1911 Add-On Key 1039410.Lee H. Jernigan Sacramento,Calif. Feb 23,1912 1042457 Vibrop1ex 1043449 Vibrop1ex 1049066 Wm.H.Engle Port Costa,Ca. Feb.21,1912 Add-on Key 1059988 David Irwin Garretson NY. Feb.15,1912 Round thing 1071267 Wm.E.Shaw Sheridan,Wyo. Feb.10,1912 straight 1074831 Delaney Wireless T&T Vibroplex 1109310 Henry P.Dwyer San Francisco,Ca. Aug.5,1912 Wireless 1109818 Vibroplex 1110373 Boulter Calif. Sep.2,1913 (9-15-1914) 1124119 Book 210 1127855 missing 1140151 John J.Ghegan Newark,N.J. Apr.25,1913 Like Gold Bug Danville/ 1168696 John H.Abernethy Hampton;Va. Apr.17,1915 1173702 Clayton Bell Centralia ,MO Jun.21,1915 release type 1174029U William Finn Bloomfield,N.J. Nov.6,1915 1177778 Books 222+225 missing from library shelf 1178291 missing 1189546 Dinger Apr.15,1909 Combo W.E. 1190259 Roy M.Allen East Orange, NJ May 29,1914 90deg release 1190625 Walter Anderson Boyd Brooklyn, NY as above 1233774 Morris N.Gwinn Meadow Creek,W.Va. Sep.13,1916 ... 1260008 Vibroplex Like Electro 1304025 William C.Cozad Chicago, Ill. Feb.12,1918 springy contacts 1332951 Thos. Russell.Purman Washington,Pa. Feb.12,1918 1338497 Dunn Mar.22,1917 Like Bencher 1436541 Geo.Issac Shelton Fort Worth, Tex. May 31,1921 straight 1438107 Cornelius F.Gruetter San Francisco,Ca. Feb.12,1912
Telegraph Patents (Searchable): Gil Schlehman - K9WDY Page 3 Patent #: Name Location Date #3 Notes: 1445,226 Vibroplex 1472506U Chas.O.VanDerVort East Orange,N.J. Aug.24,1920 1483669 Lytle (Philadelphia) Jul.16,1921 Early version 1543609 Louis C.McIntosh Los Angeles,Ca. May 31,1921 Dual like 73's 1555210/211 John A.Hulit Chicago,Ill. Feb.15,1922 motorized 1557155 M-331 1640541 Wm.G.Fluharty Rockville Ctr.N.Y. Aug.1,1924 motorized bug 1657095 Axel Emanuel Senobe Nugaunee ,Mich Dec. 31,1926 straight 1718784X Hulit Filed 4 Wide 1742296 John R. Youngblood New Orleans,La. Dec.24,1927 1742297 same as above. (R.or L.handed Diamond shape on base; 1759584 Chas. Frederick McElroy Brooklyn,N.Y. Aug.7,1928 2 Levers 1960236 Emery Jul.22,1933 black multi channel 1961367U John J.Kuhn Elizabeth,N.J. Apr.12,1933 system 2109843U ultra short waves 2148028X Martin motorized three wide 2187351 John A.LaHiff New York,N.Y. Jan.9,1939 Vib.Champion 2228469 Louisville ,Ky 1943 Rotoplex 2257685X John Wm. Hidy Pocatello,Idaho Nov.15,1939 keyer (AT& 2295389 Joel W.Dickson Willmett , Ill. Dec.24,1940 2323133 Lynn G.Heatherly Whiteville, N.C. Sep.13,1941 2325631 John R.Pinelli U.S.Navy May 27,1942 2394444X Induction Radio Carrier Current Keying System 2447088 Donald Parson Jr. Framingham,Mass. Jun.5,1946 System 2476963 Pulse Gen 2481607U Wm. Walt McGoffin New York,N.Y. Nov.1,1945 Keyer 2495377 Tomas Tejera Mayorquin Havana,Cuba Apr.22,1946. Like Melehan 2526001 Bernard Breedlove Atlanta, Ga Oct .17,1950 Codetrol 2594071X French Transmission System 2988597 Alexander J.Tremblay St.Johnsbury,VT Oct.18,1957 Keyer 3037566 Richard J. Pasco S.Williamsport,PA Mar.16,1961 Char Gen 3431354 Lemuel M.Temple W.Wardsboro,Vt. Oct.22,1965 Adapter Bug 3868575X French DF system
The Specific Guidelines used to find Patent Numbers (Not searchable)
:
(Click on image to enlarge it or to reveal enlarge button.)
The Specific Patent Numbers extracted by using the preceding
guidelines (Not searchable):
(Click on image to enlarge it or to reveal enlarge button.)
A GUIDE FOR DATING THROUGH PATENT NUMBERS: 1859-1974
(May be printed and used as a portable reference card) We believe this card can prove to be indispensable for anyone interested in dating antiques and collectibles through the U. S. Registered Patent System. This data has been compiled for that purpose. When an article has more than one patent number, choose the larger number since that is the latest patent. 1859 22,477 1898 596,467 1937 2,066,309 1860 26,642 1899 616,871 1938 2,104,004 1861 31,005 1900 640,167 1939 2,142,080 1862 34,045 1901 664,827 1940 2,185,170 1863 37,266 1902 690,385 1941 2,227,418 1864 41,047 1903 717,521 1942 2,268,540 1865 45,685 1904 748,567 1943 2,307,007 1866 51,784 1905 778,834 1944 2,338,081 1867 60,685 1906 808,618 1945 2,366,154 1868 72,959 1907 839,799 1946 2,391,8S6 1869 85,503 1908 875,679 1947 2,413,675 1870 98,460 1909 908,436 1948 2,433,824 1871 110,617 1910 945,010 1949 2,457,797 1872 122,304 1911 980,178 1950 2,492,944 1873 134,504 1912 1,013,095 1951 2,536,016 1874 146,120 1913 1,049,326 1952 2,580,379 1875 158,350 1914 1,083,267 1953 2,624,046 1876 171,641 1915 1,123,212 1954 2,664,562 1877 185,813 1916 1,166,419 1955 2,698,434 1878 198,733 1917 1,210,389 1956 2,728,913 1879 211,078 1918 1,251,458 1957 2,775,762 1880 223,210 1919 1,290,027 1958 2,818,567 1881 240,373 1920 1,320,352 1959 2,866,973 1882 254,836 1921 1,364,063 1960 2,919,443 1883 269,820 1922 1,401,948 1961 2,966,681 1884 291,016 1923 1,440,362 1962 3,015,103 1885 310,168 1924 1,478,996 1963 3,070,801 1886 353,494 1925 1,521,590 1964 3,116,487 1887 355,291 1926 1,568,040 1965 3,163,865 1888 375,720 1927 1,612,790 1966 3,226,729 1889 395,305 1928 1,654,521 1967 3,295,143 1890 418,665 1929 1,696,897 1968 3,360,800 1891 443,987 1930 1,742,181 1969 3,419,907 1892 466,315 1931 1,787,424 1970 3,487,470 1893 488,976 1932 1,839,190 1971 3,551,909 1894 511,744 1933 1,892,663 1972 3,631,539 1895 531,619 1934 1,941,449 1973 3,707,729 1896 552,502 1935 1,985,878 1974 3,781,914 1897 574,369 1936 2,026,516
